RESPIRARE VT 10D Auto CPAP Machine

The Deckmount RESPIRARE VT 10D is an Auto CPAP machine designed to provide adjustable positive airway pressure therapy through CPAP, APAP and iAPAP modes. It operates across a pressure range of 4–20 cmH₂O and is designed for users requiring prescribed CPAP therapy under the guidance of a qualified healthcare professional.

The VT 10D features B-Flex comfort technology, which lowers pressure during exhalation and gradually increases pressure during inhalation when operating in Auto CPAP mode. B-Flex can be adjusted from 0–3 levels. The device also provides automatic leak compensation, Auto On/Off functionality and iRamp, with ramp time adjustable from 0–60 minutes. An alarm system provides both sound and graphic notifications for conditions including high leakage and apnea.

Integrated heated humidification is designed to add controlled moisture to the therapy airflow and can help reduce dryness of the nose and throat. The humidification level is adjustable from 0–5, while the preheat function can be enabled with a preheat time of 10–30 minutes. A 2.8-inch LCD display provides access to device information and settings, and SD card functionality is available for therapy data storage.

The VT 10D has dimensions of 250 × 181 × 114 mm and weighs approximately 1340 g. It accepts a 100–240 V, 50/60 Hz power input with a maximum input of 1.8 A. The device supports supplemental oxygen at a maximum flow of 4 L/min in CPAP mode and uses a cotton air filter. Standard 19 mm tubing and a 22 mm air outlet are specified, while a heating tube is available as an optional accessory. The listed warranty is 2 years for repair. The device is classified as CDSCO Class 2, double insulated, Type BF and IP22, and conforms to IEC 60601-1-1, IEC 60601-1-2 and IEC 80601-2-12 standards.
